Automatic Plastic Aluminum Tube Filling Machine Facial Cleaner
Sealing Machine
Product Description:
Automatic tube filling and sealing machine used for plastic,
aluminum, laminate tube. It is one of main latest products of our
company. This machine can be used for filling cream and liquid
materials. and it is characteristics with firm filling, high
precision of dosage. The three functions of filling, sealing and
batch numbering can be automatically completed, It is widely used
in pharmaceutical, daily chemical, food chemical industries. such
as filling pharmacy cream, hair colorante, toothpaste, leather oil,
glue, AB glue, Nanp-epoxy adhesive, Neoprene adhesive etc.
Convenient and quick dosage adjustment, high efficiency,
good-looking, compact structures are the features of the machine.
The tube cups can be adjusted according to the tube dimensions. The
important parts of the machine which contact directly to the
filling material are made of stainless steel (SUS304 is for general
use, and SUS316L is for pharmacy use). A special valve makes this
machine be suitable for filling cream and liquid material. It is an
ideal and economical filling machine in the pharmacy, daily
chemical and other fields.
Product Parameters:
Filling volume | 5-250ml(tube) |
Filling accuracy | ≤±1% |
Capacity | 40 tubes/min(normal type); 60-70 tubes/min(high speed type) |
Tube diameter | OD10-50mm |
Tube length | 210mm(Max. length) |
Hopper volume | 40L |
Power | 220V/380V, can be customized |
Air pressure | 1.1KW |
Equipped motor | 0.5-0.7Mpa |
Air feeding | 0.37KW |
Convulsions | 0.37KW |
Hot air | 3KW |
Dimension | 3KW |
Weight | 1800kg (approx) |
Product Application:
The tube filling and sealing machine is suitable for automatic
color code aligning, filling, sealing, date printing and end
cutting of various plastic tubes and aluminum composite tubes. It
is widely applied in daily chemical industry, medicine, food, etc.
Product Features:
1. Replace the traditional welding or bonding process, low-cost,
clean and pollution-free and will not damage the workpiece.
2. The design of the intelligent automatic frequency-following box
can protect the mould effectively without adjusting the frequency,
and can protect the mould effectively; the output is large, the
noise is small, the performance is stable and the service life is
long.
3. The welding strength is high, the sealing property is good, its
bonding strength is equivalent to the plastic body.
4. The welding process is stable, easy to operate, easy to
maintain.
5. IC precision control circuit, automatic overload protection
system. 6, using PLC control, simple operation, automatic
protection function to avoid damage caused by improper operation.
7. 4-point balance adjustment, simple adjustment of welding head.
8. Aluminum / titanium alloy spoke rod, sound wave strong stable.
9. Automatic filling, marking, sealing, cutting material, filling
stable, accurate, no noise.
Product Details:
1. Material hopper can be adopted with automatic material feeding,
mixing and heating system for viscous products.
2. LUEZE Orientation sensor from German with high accuracy.
3. The machine heat from inside of the tube and cool from outside
for sealing, compare to ultrasonic sealing this way is faster and
makes the tube with better looking. The heating system is adopted with Swiss brand air blower Leister,
and chiller for cooling system.
4. Clamping system to close and seal the tube with batch code or
expiry date information.
Our Servers:
We provide Turn-key project service to customer.
1. Factory Layout design;
2. Factory Decoration based on GMP standard;
3. Formula of products;
4. Raw material etc;
5. Machine design, whole production line from A to Z;
6. Shipping service, FOB, CFR, CIF etc;
7. Installation service. Training service, Mainte
