50L Vacuum Emulsifier Mixer Ointment Mixer Cream Homogenizer Mixer
Vacuum Mixer
Product Description:
This machine is for high viscosity, mixer machine for lab, mixer machine for
lipstick
The material under vacuum condition, using emulsifier to extruding
and bump for many times fasty and equably, and get high quality
product without bubble.
This high speed vacuum homogenizer emulsifing machine consist of
homogeneous agitator, blade agitator and Scraping stirring to get
perfect stirring type, and adopts vacuum as well, the product will
be high quality and no bubble.
The material is under vacuum condition during processing, using
emulsifier to extruding and bump for many times fasty and equably,
and get high quality product without bubble
This high speed vacuum homogenizer emulsifing machine consist of
homogeneous agitator, blade agitator and Scraping stirring to get
perfect stirring type, and adopts vacuum as well, the product will
be high quality and no bubble.
Product parameters:
| Capacity (L) | Homogenizer | Agitator | Vacuum pump | Heating system |
| power (kw) | speed (rpm) | power (kw) | speed (rpm) | power (kw) | Limit vacuum | Electric heating (kw) | Steam heating (Mpa) |
| 5 | 0.55 | 0-3600 | 0.4 | 0-65 | 0.37 | -0.1 | 6 | 0.2 |
| 10 | 1.1 | 0-3600 | 0.55 | 0-65 | 0.37 | -0.1 | 6 | 0.2 |
| 20 | 1.5 | 0-3600 | 0.55 | 0-65 | 0.37 | -0.1 | 9 | 0.2 |
| 50 | 3 | 0-3600 | 0.75 | 0-65 | 0.75 | -0.1 | 12 | 0.2 |
| 100 | 4 | 0-3600 | 1.5 | 0-65 | 1.5 | -0.1 | 24 | 0.2 |
| 200 | 5.5 | 0-3600 | 1.5 | 0-65 | 2.2 | -0.1 | 28 | 0.2 |
| 300 | 7.5 | 0-3600 | 3 | 0-65 | 2.2 | -0.1 | 32 | 0.2 |
| 500 | 11 | 0-3600 | 4 | 0-65 | 4 | -0.1 | 50 | 0.2 |
| 1000 | 15 | 0-3600 | 5.5 | 0-65 | 4 | -0.1 | 54 | 0.2 |
| 2000 | 18.5 | 0-3600 | 7.5 | 0-65 | 5.5 | -0.1 | recommend steam heating | 0.2 |
| 5000 | 22.5 | 0-3600 | 15 | 0-65 | 7.5 | -0.1 | 0.2 |
| The parameters for reference only, all the machines can be
customized accordingly. |
Product Application:
The vacuum emulsifying mixer are mainly used to make high viscosity
emulsions, especially creams, ointments and lotions. The functions
of heating, cooling, dissolving, emulsification and vacuum
defoaming can be completed at one time with an emulsifier; the raw
materials can be fully pulverized, mixed, emulsified and
homogenized to increase the gloss and stability of the product.
Cover Accessaries:
1. View window;
2. Vacuum pressure gauge and vacuum pipe;
3. Raw material inlet (can suck raw material into main tank
directly);
4. Air filter (to release vacuum state);
5. Fragrance hopper;
6. CIP inlet;
7. LED light;
8. Compressed air inlet (if needed)
Product Details:
Stainless Steel Jacket Structure:
Material product contact layer (inside layer): stainless steel
316L, 6mm thickness, 300 mesh polishing
Middle layer: stainless steel 304, 5mm thickness, to input
water/steam/conducted oil for heating
Outer layer: stainless steel 304, 3mm thickness, for anti-scald
protection.
Our Service:
We provide Turn-key project service to customer.
1. Factory Layout design;
2. Factory Decoration based on GMP standard;
3. Formula of products;
4. Raw material etc;
5. Machine design, whole production line from A to Z;
6. Shipping service, FOB, CFR, CIF etc;
7. Installation service. Training service, maintain.
